HWATEK WIRES و CABLE CO.، LTD.
|
|
تفاصيل المنتج:
شروط الدفع والشحن:
|
| مادة غمد: | PVC | مادة العزل: | PVC ، SR-PVC ، PE أو PP |
|---|---|---|---|
| شكل المواد: | سلك مستدير | نوع الموصل: | معلب أو عاري ، تقطعت بهم السبل أو النحاس المفرد |
| موصل AWG: | 26-14AWG | درجة الحرارة المقدرة: | 80 درجة مئوية |
| الجهد المقنن: | 300V | أقصى مقاومة للموصل: | 74.5 Ω/km (مقابل 0.25 مم مربع) ، 59.4 Ω/km (مقابل 0.34 مم مربع) |
| نوع الدرع: | درع حلزوني أو بلحمة مع درع نحاسي أو عاري المليار. | مادة سترة: | PVC |
| اختبار اللهب: | UL VW-1 و CSA FT1 اختبار اللهب العمودي | رقم السلك الأساسي: | 2C-50C (اختياري) |
| سمك الاسمية: | 0.80 مم (عزل) ، 1.0 مم (سترة) | القطر الاسمي: | 2.20-2.35 مم (عزل) ، 6.7-8.3 مم (سترة) |
| الكمية لكل لفة: | 305m ، 610m أو كطلب | ||
| إبراز: | UL2464 flame retardant control cable,300V industrial PVC cable,flexible industrial control cable,300V industrial PVC cable,flexible industrial control cable |
||
| Attribute | Value |
|---|---|
| Sheath Material | PVC |
| Insulation Material | PVC, Sr-PVC, PE or PP |
| Material Shape | Round Wire |
| Range of Application | Industrial Control |
| Brand | Hwatek |
| Color | Optional |
| Qty/Roll | 305m, 610m or as Request |
| Transport Package | Rolled in Reels, Packed in Pallets |
| Trademark | Hwatek |
| Origin | China |
| HS Code | 8544492100 |
Products are used in industrial machinery, instruments, industrial control systems, electronic and electrical equipment.
For wiring of sensor.
UL758 & UL1581 & CSA C22.2 No.210
Rated temperature: 80ºC
Rated Voltage: 300V
| Product Number | Conductor | Insulation | Jacket | Max. Cond. Resistance (200C) Ω/km |
|---|---|---|---|---|
| HT2464M**0001 | 3 cores, 0.25mm², 30/0.1, 0.60mm | 0.80mm, 2.20mm | 1.0mm, 6.7mm | 74.5 |
| HT2464M**0002 | 4 cores, 0.25mm², 30/0.1, 0.60mm | 0.80mm, 2.20mm | 1.0mm, 7.3mm | 74.5 |
| HT2464M**0003 | 5 cores, 0.25mm², 30/0.1, 0.60mm | 0.80mm, 2.20mm | 1.0mm, 7.9mm | 74.5 |
| HT2464M**0004 | 3 cores, 0.34mm², 42/0.1, 0.75mm | 0.80mm, 2.35mm | 1.0mm, 7.1mm | 59.4 |
| HT2464M**0005 | 4 cores, 0.34mm², 42/0.1, 0.75mm | 0.80mm, 2.35mm | 1.0mm, 7.6mm | 59.4 |
| HT2464M**0006 | 5 cores, 0.34mm², 42/0.1, 0.75mm | 0.80mm, 2.35mm | 1.0mm, 8.3mm | 59.4 |
Remark: Optional core wire number 2C-50C, and shielding way
Founded in 2004 with 9 million USD capital investment, our HQ factory in Kunshan covers 14980 square meters.
In 2020 we established our Nantong facility with 100 million RMB capital investment which covers 34000 square meters.
With ISO9001, ISO14001, IATF16949, ISO13485 system certificates, all of our products have passed CCC, UL, CUL, CE, CSA, ETL safety certificates. We are working with global customers in various fields through our well-established sales system based on the management principal HONESTY, INNOVATION and ENVIRONMENTAL PROTECTION.
